COMBAR ALLOY PRADO 150 10/17 ON AF20 MATT BLACK

ALLOY WINCH BAR

Expanding the ARB Alloy bar range, the Alloy Summit Combination Bar is now available for Toyota Prado 150 10/17 on now finished in Matt Black powder coat.  Matt Black powder coat enables the customer to colour code if desired while receiving the weight saving benefits that comes with the ARB Alloy range. Manufactured in ARB’s state of art facility ensures quality, reliability and strength expected from an ARB manufactured product.


FEATURES:


• Vehicle specific design for the Toyota Prado 150 10/17 on.
• Registered design of styling and design components.
• 5mm alloy used for bar uprights. 4mm alloy used for wings and pans. 3mm wall thickness tube used in both 60mm and 48mm outer frames and cross piece.
• Incorporates ARB’s renowned multi fold upswept and tapered wing design for optimum strength and approach angle.
• 30mm radius on wings and centre section.
• Engineered, air bag compatible mounting system secures to the chassis via high tensile bolts.
• Split pan design for maximum strength and airflow.
• Extensive steel protection panels on centre and either side.
• Pressed form top pan and polished aluminium winch cover panel.
• Durable three piece buffers.
• Will accommodate Warn, Magnum, Bushranger Smittybilt low mount model electric winches up to 10,000lb. Separate winch mount kit 3521070 is required.
• Provision to accommodate ARB Intensity LED’s and a range of Bushranger.
• Provision for optional  ARB Fog light kit, halogen or LED. OE Fog lights can also be re used.
• Includes ARB LED Indicator and Clearance light.
• Provision for front parking sensors
• Two aerial brackets located on the top of the centre cross tube.
• Bar adds approximately 185mm to the overall length of the vehicle.
• No Hi Lift jack points provided on the ARB Alloy bar.
• Matt Black Powder Coat and can be colour coded
