BONDI W/BAR SUIT JL 18ON

ARB BONDI DELUXE BUMPER

Inspired by the popular classic ARB TJ Wrangler bumper styling, ARB has designed a completely new look bumper to suit the JL. Ruggedness is ensured by the new single piece, press formed centre pan perfectly complemented by a bash plate underpanel. Further protecting the vulnerable engine components is a low slung, forward facing 76.1mm top tube.

The new Bondi Deluxe Winch bar is recovery ready with two highly visible red chassis mounted, 8T rated recovery points and centrally located high lift jacking points.

FEATURES:

• Vehicle specific design to complement the Jeep Wrangler JL
• Durable steel construction for maximum protection
• Single-piece press formed centre pan
• Bash plate under panel included for added protection finished in vintage silver
• Twin high lift jack points in the bar perfect for use with ARB Jack or a mechanical jack
• Two aerial or driving light brackets located on the top of the centre tube
• Will accommodate Warn, Bushranger and Smittybilt low mount model electric winches up to 10,000lbs
• Provision to accommodate ARB Intensity LED’s and a range of Bushranger lights
• Provision for OE Fog Lights. Refer fog light section below for additional parts required Brackets provided to accept either OE halogen or OE LED fog lights
• Dual chassis-mounted recovery points, powder-coated red for maximum visibility
• Bumper adds approximately 34mm to the overall length of the vehicle

• Approximate weight of the bumper, chassis mounts and fitting kit is 143lbs
• Approximately 42lbs is removed from the vehicle for fitment of the bar
• Zinc rich primer for additional corrosion resistance, followed by a textured Integrit black powder coat finish
• Chassis mounts manufactured with 5mm sheet steel
• Separate winch cradle manufactured from a combination of 4mm and 5mm sheet steel
• 76.1mm forward-facing top tube
• Wings and pan manufactured from 3mm sheet steel including press forms and multi folds for added structural integrity
• Wings designed to suit the flares of Rubicon models will also suit Sport and Sahara models with Rubicon or aftermarket front flares fitted
• Uprights manufactured from laser-cut 4mm sheet steel
• Fog light brackets provided to accept either OE halogen fog lights or OE LED fog lights
